Epson EMP-TW1000 User Manual

2-10
EMP-TW1000
SEIKO EPSON Revision:A
2.4 Interface Connectors
The MA board / IF board includes interface connectors for external devices such as video
equipment and external control. The MA board / IF board is equipped with the following
connectors.
Figure 2-10. IF Board External Connectors
Figure 2-11. MA Board / IF Board Block Diagram
D Port
Rs-232c PortS-video PortVideo PortTrigger Out Port
HDMI PortPC PortComponent Port
CN102
CN101
CN100
CN300
J300
CN3001
MA Board side
D
Component
PC
HDMI
Video
S-Video
