Epson EMP-TW1000 - COMPONENTS, CONNECTORS AND SWITCHES; EXTERNAL COMPONENTS IDENTIFICATION

1-3
EMP-TW1000
SEIKO EPSON Revision:A
1.2 Components, Connectors and Switches
1.2.1 External Components
Figure 1-1. Main Unit Front
Figure 1-2. Main Unit Bottom
Control Panel
Air Exhaust Vent
Remote Control Light-receiving Area
Horizontal Lens Adjustment Dial
Vertical Lens Adjustment Dial
Zoom ring
Focus ring
Suspension Bracket Fixing Points (4 Points)
Remote Control Light-receiving Area
Air Filter
Power Inlet
Suspension Bracket Fixing Points (4 Points)
Front Adjustable Foot
