C A U T I O N
Fold the EMI suppressor;B along the dotted line and attach it on the Cable
SW;Au while wrapping the Cable SW;Au as shown in Figure 4-10.
Figure 4-10.
EMI suppressor;B
Cable SW;Au
EMI suppressor;B
