Epson EMP-TW1000 - REMOVING LMP INTAKE DUCT, LAMP FAN, AND LAMP FAN GUARD

4-37
EMP-TW1000
SEIKO EPSON Revision:A
C A U T I O N
 When installing the Inshulock T-18S, pay attention to the following
instructions.
1). Route the Exhaust Fan Cable and TH Board Assy. Cable as shown in
Figure 4-32. Make sure not to let the parts of the cables shown in the
dotted circle slacken.
2). Cut off the excess length of the Inshulock T-18S.
Figure 4-38.
Inshulock T-18S
Exhaust Fan Cable
TH Board Assy. Cable
