Epson SC-T5100 User Manual

E
Place the roll paper on a
at
surface and then
insert the spindle.
With the black ange is on the right, orient the
roll paper so that the leading edge is as shown
in the gure below.
F
Push the
ange
to the roll paper until there is
no gap between the ange and roll paper.
G
Attach the transparent ange and push it until
there is no gap between the
ange
and roll
paper.
If there are gaps between the anges at both
ends and the roll paper, the paper may be fed
skewed resulting in an error.
H
Orient the paper roll so that the black
ange
of
the spindle is on the right side and then insert
the spindle shas into the cavities in the le and
right of the spindle holder.
I
Check that the leading edge of the roll paper is
not bent and then insert it into the paper slot
until you hear a beep.
c
Important:
Hold the paper edges and insert the paper
straight into the paper slot. Inserting it
skewed will cause a skew error or paper jam.
Note:
If the leading edge of the roll paper is not
horizontal or not cut cleanly, it will be cut
automatically
aer
loading completes. However, it
will not be cut if Auto Cut is set to O.
J
Close the roll paper cover and cut sheet cover.
K
On the displayed screen, set the paper type that
matches the loaded paper and set remaining
amount management if necessary.
Not setting the appropriate paper type will
cause print quality trouble. See the following for
more details on the paper types and remaining
amount settings.
U “For Roll Paper” on page 39
SC-T5100 Series/SC-T3100 Series/SC-T5100N Series/SC-T3100N Series User's Guide
Loading and Setting the Paper
29
