Chapter 4 Handling
169
4
*1 : The values for the Rotation Settings in the table are those when [Orientation] in [Page
Layout] tab is se to “Portrait.” When it is set to “Landscape,” the description is changed as
below.
"Normal, Rotate 180 Degrees" ➔ “Rotate 90 Degrees, Rotate 270 Degrees"
"Rotate 90 Degrees, Rotate 270 Degrees" ➔ "Normal, Rota
te 180 Degrees"
*
2 : By the combination of the specific paper type and the Symbol, the following conditions are
available.
Wrist Band & Code128 : Element = 5 dots (D-grade)
Wrist Band & Codabar : Element = 5 dots,
Element ratio = 2.5 (C-grade)
•Bar Height:Sets the element height with dots. Specified dots indicate the actual
print size.
•Adjust Bar Width: Narrows the element width when printing. Make sure to select it
only when the barcode is not clear enough to be read.
•HRI Character Position: Select the position of the HRI characters. Select [Do Not Print] when
not printing.
•HRI Font: Select the HRI character font size.
• Element Rati
o: Sets the thick element width by the ratio to the thin element width.
•Character Spacing:Sets the character spacing (interval) by the ratio to the thin element
width.
•Auto Convert to Minimize Entire Symbol Width:
Selectable when CODE128 is specified. This fun
ction minimizes the
number of symbol characters required to express t he given data
string.
When “Module” is set to an odd number and the resolution is changed by changing [Cate-
gory] or [Print Quality], the printed barcode size may be changed. The barcode size can be
checked by [Size Display] button.
The printing position is limited for some types.
To Next Page
