Click [Add].
The selected barcode font is saved and the font name is added to the font list.
Specifying the barcode data
Specify the barcode data by referring to the following descriptions.
About the composite symbol:
The composite component type is selected automatically depending on the digit number of
the data. (CC-C is selected only when GS1-128 is set.)
About the HRI character:
When the total width of the HRI character is larger
than that of the barcode, the HRI character
width is set as the barcode width.
UPC-A
❏ Normal
•Specify the data of 11 to 12 digits.
•The first digit is an unchecked number system character.
•For data of 11 digits, a check digit is automatically added.
•For data of 12 digits, the 12th digit is regarded as a check digit, but not proved.
❏ Composite (difference from Normal)
•For data of 12 digits, the 12th digit is ignored, and a check digit is automatically added.
• The barcode font can be registered up to 30.
• The barcode font setting can be overwritten by clicking [Save] after selecting the font
name from the font list and changing the setting.
• The barcode font setting can be deleted by clicking [Delete] after selecting the font name
from the font list.
• Test print is executed according to the setting by clicking [Print] after inputting the text in
the box.
Composite Component Type Encodable Digit Number
CC-A 1 ~ 56 digits
CC-B 1 ~ 338 digits
CC-C 1 ~ 2361 digits
