Chapter 1 Product Overview
41
1
Paper type Fine Media Label
Form Roll paper
Backing paper width 30 to 112 mm
Label width 25.4 to 108 mm
Label length 25.4 to 1117.6 mm
(For the label length of 15 to less than 25.4 mm, use paper whose
outer edges are removed only on the right and left.)
Gap between labels 3 to 6 mm
Edge cutoff on left/right side 2 ± 0.5 mm
Label edge R 2 mm or less
Black mark width 13 mm or more
Black mark length 5 mm or more
Black mark centering position 8.5 ± 1 mm
Black mark interval 15 to 1117.6 mm
Paper thickness 0.145 mm
Roll paper core Outside diameter: 56.8 mm
External diameter Maximum 101.6 mm
Winding direction Printing face must be facing outside.
• Do not use the paper with a hole or cutout.
• when using this type of paper, the label end and the black mark end of the black mark
position on the die-cut label must be matched.
