42
Paper type Synthetic Media Label
Form Roll paper
Backing paper width 30 to 112 mm
Label width 25.4 to 108 mm
Label length Only the Black Mark Die-Cut Label
15 to 1117.6 mm {0.59" to 44"}: use paper whose outer edges are
removed only on the right and left.
Gap between labels 3 to 6 mm
Edge cutoff on left/right side 2 ± 0.5 mm
Label edge R 2 mm or less
Black mark width 13 mm or more
Black mark length 5 mm or more
Black mark centering position 8.5 ± 1 mm
Black mark interval 15 to 1117.6 mm
Paper thickness 0.195 mm
Roll paper core Outside diameter: 44.1 mm
External diameter Maximum 101.6 mm
Winding direction Printing face must be facing outside.
• Do not use the paper with a hole or cutout.
• when using this type of paper, the label end and the black mark end of the black mark
position on the die-cut label must be matched.
