Chapter 1 Product Overview
43
1
Paper type Plain Media Label, Fine Media Label
Form Fanfold paper
Backing paper width 50 to 112 mm
Label width 46 to 108 mm
Label length 15 to 301.8 mm
Gap between labels 3 to 6 mm
Edge cutoff on left/right side 2 ± 0.5 mm
Label edge R 2 mm or less
Black mark width 13 mm or more
Black mark length 5 mm or more
Black mark centering position 8.5 ± 1 mm
Black mark interval 15 to 304.8 mm
Paper thickness 0.145 to 0.161 mm
Perforated line pitch: 203.2 to 304.8 mm
Perforated line form: Plain media label : 1 mm uncut, 5 mm cut
Fine media label : 1 mm uncut, 5 mm cut
Synthetic media label :
Number of folds: 500 or less
• Do not use the paper with a hole or cutout.
• When using fanfold paper, the black marks must be at least 2 mm from the perforated
lines.
• when using this type of paper, the label end and the black mark end of the black mark
position on the die-cut label must be matched.
• Make sure to keep the same position of the black marks to the perforated lines (position
that can be detected by black mark sensor) when inserting the paper from either side in
order to use the paper inserting from reverse direction.
