VT6L Maintenance 17. Felt Sheet
VT series Maintenance Manual Rev.2 129
17. Felt Sheet
WARNING
■
To shut off power to the robot system, disconnect the power plug from the power
source. Be sure to connect the power cable to a power plug.
DO NOT connect it directly to a factory power source.
performing any replacement procedure, turn OFF the Controller and
related equipment, and then disconnect the power plug from the power source.
Performing any replacement procedure with the power ON is extremely hazardous
and may result in electric shock an
d/or malfunction of the robot system.
Joint #1 Felt Sheet
(Back of Arm #1 cover
)
Joint #1 Felt Sheet
(Inside of Arm)
Joint #2 Felt Sheet
Joint #3 Felt Sheet
To Next Page
