VT6L Maintenance 8. Cable
VT series Maintenance Manual Rev.2 61
8.2 Insert or Pull out of Power Cable
Protection model Manipulator cannot insert or pull out power cable.
Name
Quantity
Note
Tool
Cross-point screwdriver (No. 2)
1
For cross-recessed screw
Power Cable
Pull out
S
tandard
C
leanroom
(1)
Turn OFF
the Manipulator.
(2)
Remove
the power cable cover.
Reference: 7.6 Power Cable Cover
(3)
Remove the power cable clamp.
(4)
Disconnect
the power cable connector.
When removing the power cable connector, pull it out with pushing clips on
both sides
of
the connector.
Power Cable
Insertion
S
tandard
C
leanroom
(1)
Connect
the power cable connector.
(2)
Mount
the power cable clamp.
(3)
M
ount the power cable cover.
Reference: 7.6 Power Cable Cover
NOTE
NOTE
