Managing Hardware with CLI Commands
Determining Operating Status 5-25
Output Fields for the show port Command
Table 5-29 describes the output fields for the show port command (in any mode).
Table 5-30 lists the port types.
EXTREME The card is running well above normal operating temperature. The lifespan of the card will be
reduced if this condition persists. The ambient temperature of the room is likely too hot, or the
chassis air filter or fans might need cleaning or replacing. Typically this temperature is over 176°F
(80°C) for either a controller card or a traffic card.
3
N/A Temperature does not apply to this unit, or this unit does not have a built-in temperature sensor.
1. The system generates a minor alarm if the controller card temperature is 167°F (75°C) for longer than five minutes; if the condition
persists longer than one hour, the system reloads.
2. The system generates a minor alarm if the traffic card temperature is 167°F (75°C) for longer than five minutes; it generates a major
alarm if the condition persists longer than one hour.
3. The system reloads if the controller card temperature reaches 180°F (82°C); the system generates a major alarm if the traffic card
temperature reaches 212°F (100°C).
Table 5-29 Output Fields for the show port Command
Field Value/Description
Slot/Port slot/port—Slot and port numbers for this port.
Type port-type; see Table 5-30 for a list of port types.
State Port status (combination of the Admin state and Line state fields):
• Down—Port has been configured to be Up, but is not working.
• Down - not entitled—Port is on the low-density version of the traffic card and is not available.
• No card—Port has been configured, but the card is not installed.
• Unconfigured—Port is not configured and down.
• Up—Port is working (active).
Table 5-30 Port Types
Port Type Description
atm ATM OC-3, ATM OC-12 port
ethernet Ethernet or GE port (any version)
oc192 Packet over SONET/SDH port (OC-192c/STM-64c)
Table 5-28 Descriptions of Temperature Conditions (continued)
Condition Description
