Planning the Site and Installation
3-6 SmartEdge 1200 Router Hardware Guide
Physical Specifications
Table 3-8 lists the SmartEdge 1200 physical specifications.
Operating altitude 0 to 10,000 ft (3,048m)
Earthquake Telcordia 63-CORE Zone 4-compliant
Thermal dissipation, maximum 3840 watts (13,103 BTU/hour)
1. Short term refers to a period of time not more than 96 consecutive hours and a total of not more than
15 days in one year (360 hours in any given year, but no more than 15 occurrences during that year).
2. Long term refers to normal operating conditions.
Table 3-8 SmartEdge 1200 Physical Specifications
Mechanical Specification Value
1200s chassis dimensions 19.5 inches (49.50 cm) height
17.3 inches (43.80 cm) width
22.7 inches (57.7 cm) depth
1200n chassis dimensions 21.2 inches (54.0 cm) height
17.3 inches (43.8 cm) width
22.7 inches (57.7 cm) depth
Chassis weight 55 lb (25 kg) all card slots empty, ready for installation
110 lb (50 kg) all card slots filled
Chassis mounting 19- or 23-inch rack
To t a l sl o ts 14
Traffic card slots 12
Common equipment slots 2
Card dimensions 9.75 inches (24.80 cm) height
12.73 inches (32.30 cm) depth
Note Chassis depth dimension includes the front cable tray and the power safety cover.
Table 3-7 Environmental Requirements (continued)
Specification Value
