Transceiver-Based Gigabit Ethernet Cards
2-14 SmartEdge 1200 Router Hardware Guide
10 Gigabit Ethernet
The 10 Gigabit Ethernet (10GE) card is designed for traffic management, with the second generation of the
PPAs, each of which supports 1 GB of memory and can process data internally to match the speed of the
port, which runs at 10 Gbps. Any of the following types of 10-Gbps XFP transceivers are supported on the
port:
• 10000Base-SR
• 10000Base-LR
• 10000Base-ER
Table 2-11 lists the 10GE card specifications for the various XFP transceivers.
Caution Risk of data loss. You can corrupt the system if you attempt to install transceivers (GBICs,
SFPs, or XFPs) that are not purchased from Redback because these items have not been tested
with the SmartEdge router. To reduce the risk, install only the transceivers purchased from
Redback.
Table 2-11 10GE Card Specifications
Specification SR LR ER
Number of ports
1
1. The port has separate connectors for the transmit (Tx) and receive (Rx) circuits.
111
Speed 10 Gbps 10 Gbps 10 Gbps
Protection None None None
Interface 10GBase-SR 10GBase-LR 10GBase-ER
Line code 64B/66B 64B/66B 64B/66B
Negotiate flow control
2
2. The extent of the support for flow control depends on the release of the SmartEdge OS.
Yes Yes Yes
Transceiver type XFP XFP XFP
Compliance IEEE 802.3ae, 802.3 LLC,
802.3 SNAP/LLC, 802.3ae
IEEE 802.3ae, 802.3 LLC,
802.3 SNAP/LLC, 802.3ae
IEEE 802.3ae, 802.3 LLC,
802.3 SNAP/LLC, 802.3ae
