Gas Pressure Table - DX1000 Gas Type
Propane (AUS)
or ULPG (NZ)
Natural Gas
Minimum Inlet Pressure - Pre-Regulator 2.75 kPa 1.13 kPa
Maximum Inlet Pressure - Pre-Regulator 5.0 kPa 5.0 kPa
Operating Pressure when on high - (Point B or C) 2.32 kPa ±5% 0.82 kPa ±5%
Operating Pressure when on low - (Point B or C) 0.72 kPa ±5% 0.28 kPa ±5%
Max operating pressure - at burner jet 2.30 kPa 0.76 kPa
Operating pressure - Post-Regulator (Point A) 2.30 kPa 1.00 kPa
Gas Pressure Table - DX1500 Gas Type
Propane (AUS)
or ULPG (NZ)
Natural Gas
Minimum Inlet Pressure - Pre-Regulator 2.75 kPa 1.13 kPa
Maximum Inlet Pressure - Pre-Regulator 5.0 kPa 5.0 kPa
Operating Pressure when on high - (Point B or C) 1.96 kPa ±5% 0.76 kPa ±5%
Operating Pressure when on low - (Point B or C) 0.96 kPa ±5% 0.28 kPa ±5%
Max operating pressure - at burner jet 1.94 kPa 0.75 kPa
Operating pressure - Post-Regulator (Point A) 2.30 kPa 1.0 kPa
Loosen test point A (shown in the previous diagram) and attach a manometer tube in preparation for
measuring the operating pressure - post regulator. Alternatively, remove one burner and ax the
manometer tube to the burner jet.
Turn the fire on high and adjust the operating pressure at the regulator.
Once the operating pressure - post regulator - is set, check the operating pressure at test point B or C
(shown in the first diagram of this section).
Ensure all other gas appliances within the house are also operating at maximum. If the operating
pressure does not read within 5% of the table above then remove the cap from the gas pressure
regulator within the appliance and adjust the threaded spring stop. The true adjusted pressure can only
be read with the cap replaced.
