PLATINOUS SERIES CONTROLLER MANUAL
8
2.2. Trend Graph
Horizontal Axis
The horizontal axis determines the data sampling interval. The time scale can be selected between
10 minutes and the Max. Rec. time set on the Sampling Setup Screen.
Range Control
Expand
: Increases the displayed scale.
Reduce
: Decreases the displayed scale.
Display Control
The displayed position of the graph can be shifted to the left or right.
ç
: Scrolls the data to the left.
è
: Scrolls the data to the right.
To Next Page
