PLATINOUS SERIES CONTROLLER MANUAL
59
5.11.8. Register User Password
To prevent access to the chamber configuration mode, a password can be registered
with the instrumentation. Setting a password will required that the password be input
before any of the setup screens can be accessed. If it is not necessary to protect
settings, then a password need not be entered.
1. Select the Register User Password item.
Press the 7 box on the Chamber Configuration screen.
2. Input a password.
Input the name from the keypad and press the Enter key.
Passwords can be a maximum 12 characters long. To cancel a registered password,
press the Clear key followed by the Enter key n the keypad.
Note
Do not forget your password.
5.11.9. Sensor Offset
This screen is for offsetting the temperature & humidity input from the sensor in the air
conditioner to the built-in temperature controller. Offset is one means for dealing with
changes in sensor input which occur over time or for correcting the difference between
the chamber and other measuring instruments. This feature is meant to match input to
calibrated equipment and not to correct drift.
The Corrected By value set here is applied to all monitored values including data used to
plot trend graphs and that displayed on the Chamber Monitor.
1. Select the Sensor Offset item.
Press the 8 box on the Chamber Configuration screen.
2. Set offset for the dry-bulb and wet-bulb sensors.
After making your input, the correct sensor input is displayed in the Process Value
boxes.
To Next Page
