Maintenance
Agilia - User Guide 47
Cleaning the printer
1. Insert the T-card into the rear output slot. Cleaning starts.
2. When the printer ejects the T-card, remove it.
3. Remove the film from the adhesive card and insert the adhesive card into the rear output slot (adhesive side up). When the cleaning is over, the used
adhesive card is ejected into the output box.
4. Put the ribbon and film back on the cassettes and put the cassettes back in place. (
"Printing ribbon and retransfer film" on page17
).
5. Put the cards back in the card feeder, reset the card thickness selector and close the card feeder.
6. On the LCDtouchscreen click on the return button to validate the cleaning cycle.
Specific cleaning
Cleaning the print head roller
Recommended cleaning cycle: Every advanced cleaning cycle.
Servicing accessories: Cleaning swab impregnated with isopropyl alcohol.
1. Open the door of the printer and remove the cassettes from their compartments.
2. Take a swab, press the middle so that the cotton is impregnated with alcohol.
3. With one hand, rotate the print head roller using the roll bearing (in red here).
4. While rotating the roll bearing, rub the swab on the print head roller (in black here).
5. Put the cassettes back in place and close the door of the printer.
