32 Processing Module Installation and Cabling
Video Input/Output Standards
• 1080p50/59.94
• 1080i50/59.94
• 720p50/59.94.
Analog Reference Input (Ref)
• SMPTE-170M / SMPTE-318M / ITU624-4 (Black Burst)
• SMPTE-274M / SMPTE-296M (Tri Level Sync)
Note
The Ref Signal applied must match the system’s video
reference configuration.
Connector Type
HD-BNC
Processing Module 32×16 SDI Configuration
The Processing Module 32×16 is equipped with 4 SDI-IO boards.
This provides:
• 32 SDI inputs
• 16 SDI outputs
• 1 analog output reference.
Note
• The Sync Output (Located on Card 2) should be connected
to the GPU Sync Card). The other Ref Out connectors
should not be used.
