Introducing the FTB-2/FTB-2 Pro and FTB-4 Pro

FTB-2/FTB-2 Pro and FTB-4 Pro 11

Working With FTB and FTBx Modules

FTBx module

FTB module

Front

FTBx module

FTB module

Back

Connector pins

Retaining screw hole

for the retaining screw

located on the unit’s

left panel
