Introducing the FTB-2/FTB-2 Pro and FTB-4 Pro
12 FTB-2/FTB-2 Pro and FTB-4 Pro
Working With FTB and FTBx Modules
Because the two types of modules have different sizes, you need a module
adapter to work with FTB modules if your unit is not already equipped with
such adapters. The adapters must be removed before inserting FTBx
modules.
For more information on how to install or remove the adapters,
see Installing or Removing FTB Module Adapters on page 40. For more
information on how to insert or remove modules, see Inserting and
Removing Test Modules on page 45.
FTBx module FTB module
Adapter
for FTB modules
Front locking screws
Retaining screws
(serve also as front locking
screws)
