Preparing for Automation

FTB-2/FTB-2 Pro and FTB-4 Pro 271

Configuring Your Instruments

To define a LINS offset value:

1. From the main window, tap the System Settings button.

2. Tap Remote Control Configuration.

3. If necessary, tap Change settings, and then, when the application

prompts you to authorize the changes to your unit, select Yes.
