Getting Started with Your Unit

FTB-2/FTB-2 Pro and FTB-4 Pro 43

Installing or Removing FTB Module Adapters

To remove the FTB modules adapters:

1. Using a screwdriver, turn the retaining screw counterclockwise until it

is loose. Since it is a captive screw, you cannot remove it completely.

Turn retaining screw

counterclockwise
