Getting Started with Your Unit

44 FTB-2/FTB-2 Pro and FTB-4 Pro

Installing or Removing FTB Module Adapters

2. Place your fingers just under the protruding edge on the faceplate of

the adapter, and then slide the adapter out of the unit.

3. If necessary, repeat the steps above with the second adapter.

You are now ready to work with FTBx modules.

Protruding edge
