Getting Started with Your Unit

54 FTB-2/FTB-2 Pro and FTB-4 Pro

Inserting and Removing Test Modules

4. If you are working with an FTB module, proceed as follows:

4a. Turn one locking screw counterclockwise until you can remove it

completely.

4b. Remove the three remaining screws in the same way.

4c. Position the unit so that the left panel is facing you.

Turn locking screw

counterclockwise
