Test Results
294 FTB-700G/800 Series
Alarms/Errors
ODUx LOFLOM, AIS, OCI, LCK, BDI, FSF, BSF, FSD,
BSD
TIM 314
BEI, BIP-8 -
ODUx-TCM BDI, BIAE, IAE, LTC TIM 317
BEI, BIP-8 -
OPUx AIS, MSIM, CSF PLM 319
OTUx AIS, BDI, BIAE, IAE, LOF, LOM, OOF, OOM TIM 320
FAS, MFAS, BIP-8, BEI -
PTP - Loss Sync, Loss Announce,
Unusable, QL Mismatch
324
QoS Metrics - Frame Loss, Out-of-Seq. 325
S-OAM RDI, AIS, LCK, C-LOS, C-FDI, C-RDI, C-DCI
a
Loss Continuity, Mismerge,
Unexp MEG Lvl, Unexp MEP,
Unexp Period
326
Section/Line /
RS/MS
LOF-S/RS-LOF, SEF/RS-OOF, AIS-L/MS-AIS,
RDI-L/MS-RDI
TIM-S/RS-TIM 330
FAS-S/RS-FAS, B1, B2, REI-L/MS-REI -
STS-x / AU-x AIS-P/AU-AIS, LOP-P/AU-LOP,
UNEQ-P/HP-UNEQ, PDI-P, RDI-P/HP-RDI,
ERDI-PCD/ERDI-CD, ERDI-PPD/ERDI-PD,
ERDI-PSD/ERDI-SD
TIM-P/HP-TIM, PLM-P/HP-PLM 332
B3, REI-P/HP-REI -
SyncE - ESMC, QL Mismatch 335
TCM
(SONET/SDH)
TC-UNEQ-P/HPTC-UNEQ, TC-LTC-P/HPTC-LTC,
TC-IAIS-P/HPTC-IAIS, TC-ODI-P/HPTC-ODI,
TC-RDI-P/HPTC-RDI, TC-UNEQ-V/LPTC-UNEQ,
TC-LTC-V/LPTC-LTC, TC-IAIS-V/LPTC-IAIS,
TC-ODI-V/LPTC-ODI, TC-RDI-V/LPTC-RDI
TC-TIM-P/HPTC-TIM,
TC-TIM-V/LPTC-TIM
336
TC-IEC-P/HPTC-IEC, TC-OEI-P/HPTC-OEI,
TC-REI-P/HPTC-REI, TC-OEI-V/LPTC-OEI,
TC-REI-V/LPTC-REI
TC-VIOL-P/HPTC-VIOL,
TC-VIOL-V/LPTC-VIOL
Layer Alarms/Errors Page
TX/RX RX only
