Safety
decal146-1269
146-1269
1. Negative rake 3. Home position
2. Increase 4. Positive rake
decal147-1681
147-1681
1. Height of cut
decal147-0288
147-0288
1. W arning—read the Operator's Manual for instructions
on torquing the blade bolt/nut to 75 to 81 N∙m (55 to
60 ft-lb).
decal147-0289
147-0289
1. Keep the battery at a
temperature above 0°C
(32°F) and below 45°C
(1 13°F)
3. Lift the cover to charge
the battery .
2. W arning—read the
Operator ’ s Manual
before performing
battery maintenance; do
not operate the machine
when the battery charger
is connected; disconnect
the battery charger
before operating the
machine.
decal147-0290
147-0290
1. W arning—light is bright; do not look directly into the light.
10
