z Remove the clutch housing with the

special tool. (Peg key)

z drain gear oil

z remove rear axle nut

z remove rear wheel

z remove brake shoeུ and rear axleཱུᇭ

z Remove the rear brake cam lever཰᧨indicator

plateཱ and camshaftི.
