z remove springཱི

z remove cotter pinུ and shaftཱུ

z remove main standྲྀ

z remove gearcase cover

z Remove paper gasket཰ and middle gear assyཱ,

z Remove output gear assy.ི

z remove carburetor

z remove intake pipe

z remove reed valve and paper gasket.
