31
z
Remove crankcase fixing shaft
z
disassemble crankcase with special tools
z
first rem
ove right crankcase cover
.
z
Remove crankcase with special tools
z
Remove crankshaft bearing with special tools
SLIDING
SHOAFT
W
arning use a new sliding shaft.
28
30
