Table 13: Port Number Assignments (in 40 Gb Mode)
Physical Port
Number (on Switch)
Has these Assigned Port Number(s).... ...with this Port Speed
25-28 25 40 Gb
25,26,27,28 10 Gb
29-32 29 40 Gb
29,30,31,32 10 Gb
33-36 33 40 Gb
33,34,35,36 10 Gb
Table 14: Port Number Assignments (in 100 Gb Mode)
Physical Port Number (on Switch) Has these Assigned Port
Number(s)....
...with this Port Speed
29-32 29 100 Gb
29,31 50 Gb
29,30,31,32 25 Gb
33-36 33 100 Gb
33,35 50 Gb
33,34,35,36 25 Gb
Note
See the ExtremeXOS 22.6 User Guide and the ExtremeXOS 22.6 Command Reference Guide
for feature-specific information about the switches and for information regarding switch
configuration.
ExtremeSwitching X590-24t-1q-2c Switch Ports and Slots
X590-24t-1q-2c switch ports and slots include:
•
24 fixed autosensing 100Mb/1 Gb/10GBASE-T ports (ports 1-24) that provide 10 Gbps copper
connectivity. Two of these ports are configurable as stacking ports.
•
One 40-gigabit Ethernet port capable of supporting passive copper QSFP+ and active fiber QSFP+
and configurable for 1x40 Gb or 4x10 Gb Ethernet mode.
•
Two 100-gigabit Ethernet ports capable of supporting passive copper QSFP28/QSFP+ and active
fiber QSFP28/QSFP+ and configurable for 100 Gb, 40 Gb, 2x50 Gb, 4x25 Gb, and 4x10 Gb modes.
For information about QSFP28 and QSFP+ optical modules, see the Extreme Networks Pluggable
Transceivers Installation Guide.
•
Ethernet management port (10/100/1000BASE-T).
•
Serial console port implemented as an RJ45 connector used to connect a terminal and perform local
management.
•
Front panel USB port.
ExtremeSwitching Switches
ExtremeSwitching and Summit Switches: Hardware Installation Guide 59
