Extreme Networks Summit1 User Manual

S
UMMIT
S
WITCH
I
NSTALLATION AND
U
SER
G
UIDE
1-3
S
UMMARY OF
F
EATURES
• Distance Vector Multicast Routing Protocol (DVMRP)
• Console command line interface (CLI) connection
• Telnet CLI connection
• ExtremeWare
™
Vista
™
Web-based management interface
• Simple Network Management Protocol (SNMP) support
P
ORT
C
ONNECTIONS
The major difference between the models of the Summit switch is the port
configurations on each switch model. Summit switches use a combination of the
following types of ports:
• Fixed 1000BASE-SX ports using 850nm duplex SC connectors
• Modular 1000BASE-LX and 1000BASE-LX10 using Gigabit Interface Connectors
(GBICs)
• 10BASE-T/100BASE-TX ports using standard RJ-45 connectors
• 100BASE-FX ports using standard SC connectors
Table 1-1 describes port configurations available on the different Summit switch models.
Table 1-1:
Summit Switch Port Configurations
Gigabit Ethernet Ports
Switch Model
Fixed
1000BASE-SX GBIC
Redundant
GBIC
10BASE-T/
100BASE-TX 100BASE-FX
Summit1 6 2
Summit2 2 1 16
Summit3 1 1 24
Summit4 6 16
Summit4/FX 6 16
Summit48 2 2 48
Summit.bk : 1OVRVW.FM Page 3 Thursday, June 18, 1998 9:27 AM
