S
UMMIT
S
WITCH
I
NSTALLATION
AND
U
SER
G
UIDE
1-11
S
UMMIT
2 F
RONT
V
IEW
S
UMMIT
2 F
RONT
V
IEW
Figure 1-4 shows the Summit2 front view.
Figure 1-4:
Summit2 front view
The Summit2 has 16 autosensing 10BASE-T/100BASE-TX ports and two Gigabit
Ethernet ports, one of which has a redundant Gigabit Ethernet port.
For information on supported media types and distances, refer to Table 1-2.
For information on Summit LEDs, refer to “LEDs,” on page 1-16.
Port status LEDs
10/100 Mbps ports
Unit status LEDs
Gigabit Ethernet ports
12345678
9 10111213141516
AMBER
GREEN
FLASHING GREEN
=
=
=
ACTIVITY
LINK OK
DISABLED
18
16151413
8765
1211109
4321
1717R
Summit.bk : 1OVRVW.FM Page 11 Thursday, June 18, 1998 9:27 AM
