S
UMMIT
S
WITCH
I
NSTALLATION AND
U
SER
G
UIDE
1-13
S
UMMIT
4 F
RONT
V
IEW
S
UMMIT
4 F
RONT
V
IEW
Figure 1-6 shows the Summit4 front view.
Figure 1-6:
Summit4 front view
The Summit4 has 16 autosensing 10BASE-T/100BASE-TX ports and 6 Gigabit Ethernet
ports. The Gigabit Ethernet ports use standard SC connectors and support 1000BASE-SX
over multimode fiber-optic cable.
For information on supported media types and distances, refer to Table 1-2.
For information on Summit LEDs, refer to “LEDs,” on page 1-16.
Unit status LEDs
10/100 Mbps ports10/100 Mbps ports
Gigabit Ethernet ports
Port status
LEDs
Gigabit Ethernet ports
12345678
9 1011121314
ACTIVITY
LINK
15 16
AMBER
GREEN
FLASHING GREEN
=
=
=
ACTIVITY
LINK OK
DISABLED
17 18 19 20 21 22
17 18 19 20 21 22
21
22201918
17
1234 5678
9 101112 13141516
Summit.bk : 1OVRVW.FM Page 13 Thursday, June 18, 1998 9:27 AM
