Serial Communication, cont’d
VTG 400/400D • Serial Communication3-10
Command/response table for SIS commands (continued)
Command ASCII Command Response Additional description
(host to VTG) (VTG to host)
Enable/disable patterns for test pattern autosequence mode
Enable pattern 1*
X2
*17# Pas01*
X2
Enable test pattern for
autosequence mode.
Disable pattern 0*
X2
*17# Pas00*
X2
Disable test pattern for
autosequence mode.
View pattern list 17#
X2
•
X2
•...
X2
•
X2
List all test patterns that have
been enabled for autosequence
mode.
On-screen display
Enable 1*18# Osd1 Enable the on-screen display.
Disable 0*18# Osd0
Disable the on-screen display.
View status 18# 1
/0 = on/off View the current status.
Raster border
Enable 1*19# Ras1 Enable the raster border.
Disable 0*19# Ras0
Disable the raster border.
View status 19# 1
/0 = on/off View the current status.
Set screen saver type
Set
X34
*20# Sst
X34
Set the screen saver type.
View 20#
X34
View the screen saver type.
Scan rate group count
View group count 50#
X25
View the total number of scan
rate groups.
Scan rate group name
Get scan rate group name
X24
*51#
X26
View the name of scan rate
group
X24
.
Test pattern count
View test pattern count 52#
X27
View the total number of test
patterns.
Test pattern name
Get test pattern name
X2
*53#
X28
View the name of test pattern
X28
.
Get test pattern name list 53#
X28
...
X28
View the list of all test pattern
names for the currently
selected scan rate.
Zap (reset to default settings)
Total reset
Esc
zXXX Zpx Reset everything: all settings
and adjustments are reset to
the factory default (rate
memory is left intact).
Reset audio
Esc
zA Zpa Reset audio settings to factory
defaults.
