Digital Brushless AC Servo Drive system - Ref. 1809 BCSD-99/116
Parameter
No.
Name Unit
Setting
Range
Factory
Setting
Setting
Invalidation
Pn303 Reserved — — — —
Pn304 Reserved — — — —
Pn305 JOG speed rpm 0 ~ 6000 500 Immediately
Pn306 Soft start acceleration time ms 0 ~ 10000 0 Immediately
Pn307 Soft start deceleration time ms 0 ~ 10000 0 Immediately
Pn308 Speed filter time constant ms 0 ~ 10000 0 Immediately
Pn309 S curve risetime ms 0 ~ 10000 0 Immediately
Pn310
Speed reference curve form
0: Slope
1: S curve
2: 1
st
order filter
3: 2
nd
order filter
— 0 ~ 3 0 After restart
Pn311 S form selection — 0 ~ 3 0 Immediately
Pn407 Notch filter 1 frequency Hz 50 ~ 5000 5000 Immediately
Pn408 Notch filter 1 depth — 0 ~ 11 1 Immediately
Pn409 Notch filter 2 frequency Hz 50 ~ 5000 5000 Immediately
Pn410 Notch filter 2 depth — 0 ~ 11 1 Immediately
Pn411 Low frequency jitter frequency 0.1 Hz 50 ~ 500 100 Immediately
Pn412 Low frequency jitter damp — 0 ~ 200 25 Immediately
Pn500 Reserved — — — —
Pn501 Coincidence difference rpm 0 ~ 100 10 Immediately
Pn502 Zero clamp speed rpm 0 ~ 3000 10 Immediately
Pn503 Rotation detection speed TGON rpm 0 ~ 3000 20 Immediately
Pn504 Reserved — — — —
Pn505 Servo ON waiting time ms -2000 ~ 2000 0 Immediately
Pn506 Basic waiting flow 10 ms 0 ~ 500 0 Immediately
Pn507 Brake waiting speed rpm 10 ~ 100 100 Immediately
Pn508 Brake waiting time 10 ms 10 ~ 100 50 Immediately
Pn509 Allocate input signal to terminal — 0 ~ 0xEEEE 0x3210 After restart
Pn510 Allocate input signal to terminal — 0 ~ 0xEEEE 0x7654 After restart
Pn511 Allocate output signal to terminal — 0 ~ 0x0888 0x0210 After restart
Pn512 Bus control input node low-bit enable 0 ~ 1111 0 Immediately
Pn513 Bus control input node low-bit enable 0 ~ 1111 0 Immediately
Pn514 Input port filter 0.2 ms 0 ~ 1000 1 Immediately
Pn515 Reserved — — — —
Pn516 Input port signal inversion — 0 ~ 1111 0 Immediately
