FENDT 926 Vario User Manual

163
CARE AND MAINTENANCE
21. Fuses
DANGER:
Use only original fuses. Excess amperage fuses can destroy the electrical system. Fire
hazard.
Fuse holder (X050, X051, F060-F067)
Operation_Pic_number:1
● Unlatch (arrow) and remove document box.
Operation_Pic_number:1
Fuse holder (X050, X051, F060-F067)
Fig.66
Fig.67
Fuse holder (A013)
Operation_Pic_number:1
● Unscrew trim panel (arrowed).
Operation_Pic_number:1
Fuse holder (A013).
Starter relay fuse (A) 24 V
Operation_Pic_number:1
Fig.68
Fig.69
Fig.70

FENDT 926 Vario Specifications

General

Engine Power	260 hp
Transmission	Vario continuously variable transmission
Fuel Tank Capacity	500 liters
Weight	10, 500 kg
Engine type	6-cylinder turbocharged
Rated engine speed	2100 rpm
Displacement	7.5 liters
Number of cylinders	6
Maximum speed	50 km/h
Tire Options	Multiple options available
