Festo control block CPX-CEC
3.3 Connection and display components
1
Status LEDs
5
DIL switch 1 ( section DIL switches)
2
RUN/STOP rotary switch
6
DIL switch 2 ( section DIL switches)
3
Ethernet interface (10/100BaseT, RJ45)
7
Connection for handheld CPX-MMI
4
CPX-CEC-C1-V3/-M1-V3:
– CANopen interface (plug, 9-pin, Sub-D)
CPX-CEC-S1-V3:
– RS-232 interface (socket, 9-pin, Sub-D)
Figure: Connection and display components
12
