Festo control block CPX-CEC
5.4 Errors and diagnostic information in SoftMotion (CPX-CEC-M1-V3)
Errors are output at the following points in SoftMotion:
– At the ErrorID output by the function block currently in control
– At the wErrorID output by the function block currently in control
– On the [SoftMotion Drive: Basic] tab:
Figure: Error message on the [SoftMotion Drive: Basic] tab
A list of possible SoftMotion error numbers can be found in the 3S online Help ( SoftMotion
[Programming Interface] [SoftMotion Libraries] [SM3] [Basic] [Data Types] [Error] [SMC_ERROR].
5.5 Errors and diagnostic information via web server
Diagnostic information is called up in the "Scan Festo Devices" dialog in the context menu of the selected
Festo device using the "Homepage" function.
Figure: Calling up the "Homepage" of the CPX-CEC module
63
