Festo CPX-CEC-S1-V3 User Manual

Festo control block CPX-CEC
Feature Description
Data interface (CPX-CEC-S1-
V3)
– Type RS232 interface
– Connection technology Socket, Sub-D, 9-pin
– Data transmission speed 9.6 ... 230.4 kbps
– Electrical isolation Yes
– Max. line length 30 m
Degree of protection IP65/IP67 (only in combination with plugs and covers with protection to
IP65/67)
Nominal operating voltage 24 V DC
Load voltage
– Without pneumatic
components
18 V DC … 30 V DC
– With Midi/Maxi pneumatic
components
21.6 V DC … 26.4 V DC
– With CPA pneumatic
components
20.4 V DC … 26.4 V DC
– With MPA pneumatic
components
18 V DC … 30 V DC
Intrinsic current consumption
– At nominal operating
voltage
Typically 85 mA
Power failure bridging 10 ms
Storage temperature -20 ... 70 °C
Ambient temperature -5 ... 50 °C
Relative air humidity 95%, non-condensing
Product weight 135 g
Dimensions W x L x H 50 mm x 107 mm x 55 mm
Table: Technical data
