12
Festo — EMCS-ST — 2021-03b
Display and operating components (HMI)
(Set value: 10, 20,..., 100% of the maximum value è drive system instruction manual, technical
data) and save (Save), press
–
Parameterise the position of the "Ref" reference end position (Set Ref) and run homing with
detection of the Mov
Ref
end position (Start
Ref
: Pos
Act
è Lim
In
è Lim
Out
), press
–
Run Start Press movement (Start/Stop) and save Start Press Position Pos
Start Press
(Save), press
–
Execute Demo Run (Start/Stop)
– Lock pushbutton actuators (Lock HMI), press and hold for 3 s or no pushbutton actuator input
for 15 s
– To acknowledge an error, press and hold for 3 s (from FW version v19.0.4.107_release)
–
Reset to factory setting, press and hold , and simultaneously for 10 s
HMI menu structure
The following figure shows the states of the LED displays for the parameters and the menu selection,
the state transitions between the menu sequences (pushbutton actuator navigation) and the motions
of the drive systems when performing motion tasks.
