Festo — EMCS-ST — 2021-03b
6 Transport and storage
Transport and storage conditions
– Store and transport the product in its original packaging.
– Store product in a cool, dry, shaded and corrosion protected environment.
–
Store product in ambient conditions without oils, greases and degreasing vapours.
– Ensure short storage times.
7 Assembly
7.1
Safety
WARNING
Risk of injury due to unexpected movement of components.
The drive can move freely in the voltage-free state. This can cause unexpected movements of the
connected mechanics and crush parts of the body.
• Bring moving parts of the mechanical system into a safe position.
7.2 Mounting clearances
Drive systems with integrated drive EMCS-ST can be connected in series. When connecting drive
systems in series, a minimum distance must be maintained to allow the heat generated during
operation to dissipate by allowing sufficient air flow.
– Maintain a minimum lateral distance of at least 20 mm between the integrated drive EMCS-ST and
adjacent components.
–
Take into account the clearance required for connecting the cables (the cables at the [Logic] and
[Power] connections can be routed upwards (straight) or laterally (angled)).
–
Do not install any temperature-sensitive components near the integrated drive EMCS-ST. The inte-
grated drive EMCS-ST can become very hot during operation.
Assembly instructions
– Mount the drive system flat on a sufficiently stable mounting surface.
– Maintain minimum clearances and installation space to guarantee sufficient air flow. The ambient
air must be able to flow unhindered around the integrated drive EMCS-ST.
7.3 Installation
• Mount the product è Instruction manual, mounting the corresponding drive.
8 Installation
8.1 Safety
WARNING
Risk of injury due to electric shock.
• For the electrical power supply with extra-low voltages, use only SELV circuits that ensure a reliable
separation from the mains network.
• Observe IEC 60204-1/EN 60204-1.
