Icons
In order to make configuration easy for you, the
diskette contains files with valve terminal icons in
directory:
A:\SIEMENS\COMWIN2\TYPE-03\BMP\
File: FE-TYP3N.200 and
FE-TYP3S.200
The icon appears, if the icon files are in the
following directory on your programmer/PC:
\COMWIN2\BITMAPS\
PLEASE NOTE
Update the slave catalogue when you copy
the type files whilst processing the COM
ET200/ COM PROFIBUS.
Menu: ”File” - ”Read type files.”
VIFB13 - 03/05 4. Commissioning
4-32
9701 NH
