Alternatively, the complete number of inputs
(including the 4 status bits) as well as the
complete number of outputs can be entered as
the sum identifier.
The DP identifiers (individual identifiers or sum
identifiers) can also be entered in the window
”Identifier ...”.
2
Type: Select inputs or outputs.
PLEASE NOTE
The I/O types ”Input/output”, ”Empty space”
etc. are not permitted.
3
Length: Enter 1 for 8 inputs or 8 outputs.
Alternatively you can enter the sum of the
inputs or outputs in bytes (gives sum identi-
fier).
PLEASE NOTE
Add the 4 status bits to the number of inputs.
4
Format: Select ”Byte” for the configuration of
the inputs and outputs. The setting ”Word”
is not permitted.
VIFB13 - 03/05 4. Commissioning
9701 NH 4-35
