8
I/O type: Select ”Input” or ”Output”.
PLEASE NOTE
”Output” or ”Empty space” are not permitted
as I/O types.
9
Address: Enter the desired periphery ad-
dress (STEP 7) or the address offset
(NCM S7).
0
Length: Enter ”1” for 8 inputs or 8 outputs.
Alternatively you can enter the sum of the
inputs or outputs in bytes (sum identifier).
PLEASE NOTE
Add the four status bits to the number of
inputs.
!
Unit: Select ”Byte” for inputs or outputs.
"Word" is not permitted.
This completes the configuration/address assign-
ment with STEP 7 V2.x or
NCM S7-PROFIBUS V2.x.
VIFB13 - 03/05 4. Commissioning
4-42
9701 NH
