Festo FB13 - Page 154

Example
Valve terminal with 40 inputs (+4 status bits) and
20 outputs.
Periphery address
Inputs: 68...73
Outputs: 68...70
Configuration Status bits
Inputs
Outputs
8DI 8DI 8DE 8DI 8DI 8DI
8DO 8DO 8DO
or Byte/octet 6, bits 4,..., 7
(I73.4 ... I73.7)
Inputs
Outputs
016 016 016 016 016 016
032 032 032
