Summary of diagnostic bytes
Byte Meaning Byte
0 Station status 1 Station status 2 1
2 Station status 3 Master address 3
4 Manufacturer identifier (FB13
H
)5
6 Diagnostic header Device-related diagnosis 1 7
8 Device-related diagnosis 2 Device-related diagnosis 3 9
10 Device-related diagnosis 4 Device-related diagnosis 5 11
12 Device-related diagnosis 6 Device-related diagnosis 7 13
Contents modified by valve terminal
Structure of station status 1
1: The valve terminal cannot be addressed
1: Terminal not yet ready for data exchange
1: Configuration data do not agree
1: Device-related diagnosis exists
1: Function not supported
1: DP master cannot interpret reply
1: Planned valve terminal type not correct
1: Access by another master
Fig. 5/13: Structure of station status 1
76543210
