Diagnostic possibilities
The Festo valve terminal offers extensive diag-
nostic posibilities via the PROFIBUS-DP. The
diagram below shows the steps necessary for
diagnosing the valve terminal. Only those diag-
nostic bits are shown which require a further
diagnostic step.
Bit
Station status 1
1: Read "device-related diagnosis 1"
Bit
Device-related diagnosis 1
1: Read device-related diagnoses 4-7
1: Read device-related diagnoses 2; 3
Fig. 5/12: Diagnostic steps
76543210
1
76543210
11
