Electronic input modules
Input voltage range
Logic level PNP
ON
OFF
Logic level NPN
ON
OFF
Current consumption
(at 24 V or 0 V) (current
from sensor to input at
logic 1)
Response delay (at 24 V)
Common fuse for operating
voltage supply to sensors
Galvanic isolation
DC 0 ... 30 V
12.5 V
7 V
5 V
11 V
max. 9 mA
typ. 5 ms
2 A, slow blowing
None
Electronic output modules
Loading
per digital output
Current consumption
(at 24 V)
Internal consumption at
logic 1
Electronic fuse
(short circuit overload)
Trigger current
Response time
(short circuit)
Galvanic isolation
max. 0.5 A (Bulbs max.
10 W because of PCT
resistor characteristics)
typ. 9 mA
max. 1.5 A
max. 1 s
None
VIFB13 - 03/05 Appendix A
9701 NH A-5
